ACS725LLCTR-05AB-T Temperature Sensor Chip Current Sensor 5A 1 8-SOIC

ACS725LLCTR-05AB-T Temperature Sensor Chip Current Sensor 5A 1 8-SOIC

Current Sensor 5A 1 Channel Hall Effect, Differential Bidirectional 8-SOIC (0.154", 3.90mm Width)

The terminals of the conductive path are electrically isolated from the sensor leads (pins 5 through 8). This allows the
ACS725 current sensor IC to be used in high-side current sense applications without the use of high-side differential amplifiers
or other costly isolation techniques.

Features of ACS725LLCTR-05AB-T

• AEC-Q100 qualified
• Differential Hall sensing rejects common-mode fields
• 1.2 mΩ primary conductor resistance for low power loss and high inrush current withstand capability
• Integrated shield virtually eliminates capacitive coupling from current conductor to die, greatly suppressing output

noise due to high dv/dt transients
• Industry-leading noise performance with greatly improved bandwidth through proprietary amplifier and filter design techniques
• High-bandwidth 120 kHz analog output for fasterre sponse times in control applications
• Filter pin allows user to filter the output for improved resolution at lower bandwidth
• Patented integrated digital temperature compensation circuitry allows for near closed loop accuracy over
temperature in an open-loop sensor
• Small footprint, low-profile SOIC8 package suitable for space-constrained applications
• Filter pin simplifies bandwidth limiting for better resolution at lower frequencies

Specifications of ACS725LLCTR-05AB-T

range (−10 ̊

Environmental & Export Classifications

with avck-

APPLICATIONS of ACS725LLCTR-05AB-T

ACS725LLCTR-05AB-T Temperature Sensor Chip Current Sensor 5A 1 8-SOIC Images
